Production Capabilities

Dielectric Materials of Construction

Applied Rigidizeding Stiffners

  • Quick Turns & Prototypes Tooled to Production Panel
  • Full D.F.M. on Proto-Type
  • Quick Turn, Proto-Type to 24 Hours
  • Small Volume - Preproduction
  • Mid Volume
  • High Volume
  • Standard Panel Size 18"x24"
  • Standard Materials Inventoried in House
  • Polyimide / Kapton - PI
    • Acrylic Adhesives
    • Adhesiveless
    • Epoxy Adhesive
    • Flame Retardant available
  • Polyester with Acrylic Adhesive - PET
  • Cast Polyimide 1 mil thickness - Adhesiveless - PI
  • Polyethylene Napthalate - PEN
  • Adhesives
    • Pressure Sensitive - PSA
    • Thermal Cure Acylic
  • Stiffner Materials
    • FR4
    • Polyimide Film
    • Glass Reinforced Polyimide
    • GETEK
    • BT
    • Metallic
    • Heat Sinks

Data Requirements and Data Transfer

Circuit Types

Cover-Coatings

  • Design :"Flexizing" Software In-House
  • Full Tooling Generation In-House
  • Gerber Data - Preferred
  • E-Mail, FTP, Modem Transfer Capable
  • Negative Data Power/Ground Planes Preferred
  • Apperatures > .010" Preferred
  • Single Sided
  • Double Sided
  • Multi-Layer
  • Rigidized Flex
  • Rigid Flex



  • L.P.I. Liquid Photoimageable / Soldermask
  • P.I.C. Photoimageable Cover-Lay (Dry Film)
  • Polyimide Film/Cover-Lay
  • Polyester Film/Cover-Lay

Metallic Surface Finishes

Automatic Optical Inspection

Elecrica.Testing

  • Immersion Silver
  • O.S.P., Organic Solderability Preservative
  • H.A.S.L., Hot Air Solder Level
  • Hard Ni/Au, Electro-Plated Nickel / Gold
  • Immersion Gold, Chemical Deposited Ni/Au
  • Soft Gold, Wire Bondable
  • Phototool
  • Inner Layer
  • Outer Layer
  • Capabilities: 250 volts DC to 100 Ohms
  • Dual Access Stiff Pin Fixtured
  • 4 Probe - Flying Probe Dual Access Fixtureless
  • Net List Capability
  • Golden Board Capability


Board Cleanliness



  • Values <2.0 Micro Grams Chloride per Square Inch
  • Ion Chromatography Verification
